OHAUS AX8201/E 8,200 x 0.1g Adventurer Precision Balance 30100619
The OHAUS AX8201/E Adventurer Precision Balance 30100619 offers an 8,200 g weighing capacity with 0.1 g readability for reliable routine weighing in laboratories, education, manufacturing and quality control applications across NZ.
Its large 195 x 175 mm stainless-steel weighing pan provides ample space for samples, containers, ingredients and production components. A responsive 4.3-inch full-colour VGA touchscreen provides intuitive operation and access to weighing, parts counting, percent weighing, check weighing, dynamic weighing, formulation, density determination, totalisation, display hold and batch printing applications. Integrated RS232, USB Host and USB Device connections provide flexible compatibility with suitable computers, printers and data collection systems. The AX8201/E uses external calibration and includes selectable calibration points, GLP/GMP data output, a real-time clock and user-defined project IDs. With durable construction and practical connectivity, the OHAUS AX8201/E 30100619 from Ansutek NZ is a versatile precision weighing solution.
Key Features
- Item number: 30100619
- Model: OHAUS AX8201/E Adventurer Precision Balance
- Maximum capacity: 8,200 g
- Readability: 0.1 g
- Internal calibration: Not applicable; external calibration required
- Repeatability: 0.1 g typical
- Linearity: ±0.2 g
- Stabilisation time: 1.5 seconds
- Minimum weight USP, 0.1% typical: 160 g
- Pan size: 195 x 175 mm
- Pan material: stainless steel
- Display: 4.3-inch full-colour VGA touchscreen
- Dimensions: 354 x 100 x 230 mm (L x H x W)
- Net weight: 3.8 kg
- Tare range: to capacity by subtraction
- AC adapter included
- Full housing in-use protective cover included
- Illuminated front level indicator
- Weigh-below hook for suspended weighing
- Security bracket and calibration lock
- Selectable environmental filters
- Auto tare function
- User-selectable span calibration points
- User-defined project and user IDs
- GLP/GMP data output with real-time clock
- Up to nine operating languages
Weighing Applications
- Standard weighing
- Parts counting
- Percent weighing
- Check weighing
- Dynamic weighing
- Formulation
- Density determination
- Totalisation
- Display hold
- Batch printing
Pan Size & Sample Compatibility
The OHAUS AX8201/E 30100619 features a large 195 x 175 mm stainless-steel pan suitable for laboratory containers, ingredients, samples, components and production items weighing up to 8,200 g.
Connectivity & Compatibility Options
- RS232 interface included
- USB Host connection included
- USB Device connection included
- Compatible with OHAUS USB Type A-B cable
- Compatible with OHAUS AD7-RS auxiliary display
- Compatible with OHAUS SF40A impact printer
- RS232-to-USB interface kit available
- Compatible with selected OHAUS RS232 communication cables
- Compatible with OHAUS anti-theft devices
- Static ioniser available as an accessory
- Terminal extension cable available
- Weigh-below hook supports suspended weighing applications
